- 124 -
Set aside the shifting fork shaft.
Remove the gearshift drum.
Remove the gearshift fork.
Inspection
Measure the outer diameter of the shifting fork shaft.
Allowable limit: 9.96mm.
Measure the inner diameter of the shifting fork hole.
Allowable limit: 10.05mm.
Shifting fork
Shifting fork
shaft
Gearshift drum
Microcalliper
Testing
gauge
