GeoVision GV-EBD4813 - GV-EBD4711; 4712; 4813; 8711; 8813 Standard Installation

Introduction
9
1
1.1.4.2 GV-EBD4711 / 4712 / 4813 / 8711 / 8813 Standard Installation
For Concealed Installation
1. Stick the drill template paster to the ceiling and drill three holes according to the drill
template.
Drill Template Paster
Figure 1-10
2. Insert the screw anchors.
Drill a hole to lead the cables out of the ceiling
Knock in screw anchors
Figure 1-11
3. Loosen the fixing screw and remove the housing by turning it to the position as shown.
1
Figure 1-12
