1.2.5.4 GV-Mount504
GV-Mount504 Packing List
• GV-Mount504
• Long Screw x 4
• Short Screw x 3
• Screw Anchor x 4
• Drill Template Paster
• Waterproof Rubber Plug
• Plastic PG21 Conduit Connector
1. Unscrew the box cover.
Figure 1-65
2. Stick the drill template paster to the wall with the arrow pointing up.
3. Drill the 4 mounting holes according to the drill template.
4. Insert the 4 screw anchors to the mounting holes.
