1.6.3 Overview
1.6.3.1 GV-FER5702
Figure 1-107
No.
Description
No.
Description
1
Power connector (DC 12V)
3
Green wire-Alarm output -
2
Ethernet connector / PoE
4
Yellow wire-Audio output
3
Brown wire-Alarm input
4
White wire-GND
3
Blue wire-GND
4
Purple wire-Audio input
3
Orange wire-Alarm output +
