Introduction
19
1
5. Thread the Ethernet cable through the center socket and waterproof the Ethernet cable.
For details, see 1.8 Waterproofing the Cable.
`
Figure 1-31
6. Fit the cable into the wall box.
7. Secure the camera by locking the provided short screws to the screw position for each
model:
GV-EBD2702 / 2704
Figure 1-32
GV-EBD4700 / 4701 / 4704 / 4711 / 4712 / 4813 / 8700 / 8711 / 8800 / 8813
and GV-EBFC5800
Figure 1-33
