GeoVision GV-EBD4813 - Page 65

52
6. Secure the transparent dome cover with the supplied torx wrench.
Figure 1-74
Note: Before securing the transparent dome cover, make sure the waterproof rubber strip is
tightly held by the six retainers on the bottom ring.
Figure 1-75
For Open Installation
Lead the cables out from the open slot on the camera base before screwing the camera to
the ceiling as shown in Figure 1-72.
