Installation Instructions
4–4 INS 61301607027 Rev A US
NOTE
26 IN. LENGTH WITH STEAM BOILER: The steam boiler extends beyond
the end of the sterilizer frame (see Figure 4–3).
FIGURE 4–3. 26 IN. LENGTH UNIT WITH STEAM BOILER
Double door units may be recessed into a wall at one end or both ends (see
Figure 4–4). Compliance with the roughing-in drawing specifications is
essential.
FIGURE 4–4. DOUBLE DOOR INSTALLATION
Steam Boiler
(option)
A07027-B
Recessed at One End (with Cabinet) Recessed at Both Ends
A07028-C
CONTROL
END
CONTROL
END
REMOTE
END
REMOTE
END
SERVICE
AREA
