35
CMD
The power ON indicator shows the battery status:
- Green indicates charged battery.
- Red indicates almost discharged battery.
- Blinking red indicates quite discharged battery. It is necessary to terminate
measurement.
If the instrument is supplied from internal batteries, their condition is
indicated on the control unit display ( ) see picture below. Indicator in the
corner marked “CU” shows the battery status of the control unit while the left
indicator marked “BT” shows the status of the Bluetooth adapter battery. The
fully charged battery is shown as . If the battery is discharged ( is
shown) finish the current measurement and charge or exchange the battery. Critical
battery discharge is signalized with periodic beeping.
Battery Charging
If the Li-Ion battery pack is included in the device and the device is
connected to the external power source (AC/DC adapter or DC power source) then
charging is turned on automatically.
The status of the battery charging is signalized by the battery status
indicator ( ) if unit powered on control light “Battery charger status”:
- The light is off charging has been finished
- Green color charging
- Red color defective battery (disconnect the external power
source immediately and exchange the battery)
GF Instruments
Conductivity Meter CMD
Probe:
SN-probe:
SN-unit:
Meas. error:
CMD-4 (3.0 / 6.0m)
#07070002 v1.0
#07070003 v1.1
Number of files:
Free memory:
2
131072 kB
C U
B T
