User manual
Checking and saving measurement
User can check measured values and if they are OK he can save them by
means of the probe button or by “Yes“ key. Then it is possible to go to the next
point.
The function of the keys is following:
- Yes / button on the probe – saves measured data and goes to the next point.
- No – cancels measured values and goes to the next point.
- 0 to 9 or - – opens window for comment and allows entering note for
measured point.
- F-key + 1 to 6 – switch over the measured value screens. See chapter
Measured value screens.
- F-key + Up / Down / Left / Right – changes scales of histograms or scale
and orientation of the displayed map if it is displayed. See chapter
Measured value screens.
Latitude:
Longitude:
Conduct.:
In-phase:
Meas. error:
48 05.333N
011 39.359E
21.3 mS
2.01 ppt
0.2 %
Save?
C U
