The function of individual keys is following:
- Yes / button on the probe – start of measurement.
- No – enter of any measuring position or stop of the measurement – allows
entering e.g. extra position which is not in the measuring grid (occurrence
of an obstacle in field). Repeated pressing of “No“ key allows to terminate
measurement of the current file.
- Up / Down – skips to the next / previous measuring point.
- Right – measuring position automatically moves to the next line and the
direction of the movement changes to the opposite. It means that operator
goes to the next line and continues measurement with opposite direction.
Press the button again to skip any line.
- Left – measuring position moves automatically to the beginning of the next
line. Measurement on that line goes with the same direction as on the
previous one. Press the button again to skip any line.
- F-key + Up / Down – setting of the measuring direction along line (y axis).
- F-key + Right / Left – setting of the measuring direction along x axis
(number of lines).
- 0 to 9 or - – opens window for comment and allows entering note for
measured point.
- F-key + 1 to 6 – switch over the measured value screens. See chapter
Measured value screens.
