The function of individual keys is following:
- Yes /button on the probe – start of measurement.
- No – enter of any position of the measurement beginning; respectively end
of the measured file (if pressed three times).
- Up / Down – movement of the starting position of the measurement to the
next / previous length mark.
- Right – measuring position is automatically moved to the next line and the
direction of measurement is changed to the opposite (operator goes to the
next line and continues measurement with opposite direction). Press the
button again to skip any line.
- Left – measuring position is automatically moved to the beginning of the
next line. Measurement goes with the same direction and the operator
must return to the beginning of that line. Press the button again to skip
any line.
- F-key + Up / Down, resp. Right / Left – setting of the direction of the
measurement along y axis or along x axis respectively.
