GF EA25 User Manual

37
Instruction manual
Electric Actuators Type EA15-250
9.3 Accessories
Designation Function Code No.
Fail-safe return unit with
integrated battery pack
In case of a power outage, the fail-safe return unit can be used to
move to a preset safe position (OPEN/CLOSE). Assembly in the
housing actuator
199 190 610
199 190 601
EA15
EA25-250
External fail-safe return unit
In case of a power outage, the fail-safe return unit can be used to
move to a preset safe position (OPEN/CLOSE). Voltage supply (24
V DC) implemented externally
199 190 611
199 190 604
EA15
EA25-250
Positioner For continuous control operation (4-20 mA / 0-10 V) 199 190 603 EA25-250
Monitoring
For monitoring control time and motor current, as well as for
extending the control times and counting the control cycles (even
without bus system) via a collective alarm
199 190 602 EA25-250
Profibus For integrating the actuator into a Profibus DP network 199 190 605 EA25-250
Diagnostic tool For reading various data for a first error diagnosis via USB 199 190 600
AS-Interface module ASEV
2400
Connection to an AS-i network (supply in combination with limit
switch kit)
199 190 562
Adapter SW 11 for F04 Modification for valves with F04 interface 198 000 587
Adapter SW 14 for F05 Modification for valves with F05 interface 198 204 057
Reducer bushing WS 11 for
F05
Adjustment for valves with F05 interface and wrench size 11 198 803 145
Standard plug set For the connection of accessories 198 000 502
Plug set 4 pin For connection of MIDDLE position feedback 199 190 606 EA25-250
EA Demo Box Box to demonstrate all functions of EA 199 190 607
Display 2-way Optical position display for 2-way valve (10 pcs) 199 190 612
Display 3-way “L” horizontal Optical position display for 3-way valve (10 pcs) 199 190 613 EA25-250
Display 3-way “T” horizontal Optical position display for 3-way valve (10 pcs) 199 190 614 EA25-250
Display 3-way “L” vertical Optical position display for 3-way valve (10 pcs) 199 190 615 EA25-250
Display 3-way “T” vertical Optical position display for 3-way valve (10 pcs) 199 190 616 EA25-250
Modbus RTU Interface Card
Modbus RTU Interface board for Electric Actuators
Type EA25 - EA250
199 190 617 EA25-250
Modbus TCP Interface Card
Modbus TCP Interface board for Electric Actuators
Type EA25 - EA250
199 190 660 EA25-250
EtherNet/IP Interface Card
EtherNet/IP Interface board for Electric Actuators
Type EA25 - EA250
199 190 661 EA25-250
PROFINET Interface Card
PROFINET Interface board for Electric Actuators
Type EA25 - EA250
199 190 662 EA25-250
M12 Ethernet Adapter Set Ethernet adapter set for version with M12 connector 199 190 663 EA25-250
