7
Instruction manual
Electric Actuators Type EA15-250
1 About this document
1.1 Other applicable documents
Document
GF Planning Fundamentals Industry 700671687
Data sheet www.gfps.com/is-manuals-valves
Chemical resistance www.gfps.com
These documents are available from the GF Piping Systems Sales Company or at www.gfps.com.
1.2 Symbols
Symbol Indication
•
Listed in no particular order.
►
Call for action: Here, something has to be done.
1. Call for action in a certain order: Here, something has to be done in the specified order.
1.3 Abbreviations
Abbreviation Indication
EA Electric actuator
AC/DC Alternating Current/Direct Current
SELV Safety Extra Low Voltage
CW Clockwise
CCW Counter Clockwise
NO Normally open contact
NC Normally closed contact
BCD Binary coded decimals
SMD Surface Mounted Device
