0.1 Operating mode
With this menu item, you select the operating mode for moving
the door during OPEN operation and CLOSE operation.
When selecting the option, note the following:
▪ the number of safety devices and safety edges at the door.
▪ the optional connection of a command device to terminals X5.
Danger due to unattended door movement!
The safety devices are deactivated in operating mode hold-to-
run. People or objects in the movement path are not detected.
▪ Operate the door only with a clear view of the door.
▪ Options
.6 or 1.6,provideadditionalsafety;thesafetydevices
remain active despite operating mode hold-to-run.
0. 1
Operating mode
►
.1
No safety device on door: hold-to-run OPEN/CLOSE
.2
No safety device on door: self-hold OPEN and hold-to-run CLOSE
.3
One safety device on door: self-hold OPEN/CLOSE
.4
One safety device on door: self-hold OPEN/CLOSE
CLOSE operation is also possible in hold-to-run with a control device on X5.
.6
One safety edge on door: hold-to-run OPEN/CLOSE. The safety edge is
active during movement.
1.3
Two safety devices on door: self-hold OPEN/CLOSE
1.4
Two safety devices on door: self-hold OPEN/CLOSE
CLOSE operation is also possible in hold-to-run with a control device on X5.
1.6
Two safety edges on door: hold-to-run OPEN/CLOSE The safety edges
are active during movement.
