2 Storage and transport
Store the door control in the original packaging in a dry place.
The temperature may be between 32 F (0 °C) and 122 F
(+50 °C).
The humidity must not exceed 93 %.
Do not stack anything on the door control. Transport the door
control in the original packaging. Avoid impacts, shocks, and
vibrations.
3 Product overview
3.1 Technical data
Property Specication
Dimensions of the control unit 340 mm x 235 mm x 125 mm
13.4“ x 9.3“ x 5“
Operating frequency 60 Hz
Adjustable operating voltages 220V / 460V / 575V
Max. output power for door drive unit 5.5 kW
External supply voltage
(internal electronic protection)
24V DC / 500mA
Inputs 24V DC / 10mA
Relay contacts 2
Load on relay contact,
resistive/inductive Ambient
24V 1A
Temperature during operation -10°C to +40°C /
14°F to 104°F
Humidity during operation max. 93%, non-condensing
Degree of housing protection IP65 / NEMA 4
Overvoltage Category II
Weight 3.5 kg
