GFA DC 8010 - 1.3 - 1.5 Fine correction of final limit positions; 1.6 Door positions for intermediate open

30
1.3-1.5Finecorrectionofnallimitpositions
Usethismenuitemtomodifythenallimitpositionsofthedoor
that have been already set. No door movement takes place
duringnecorrection.
With menu items
1.3 - 1.5 you can select the levels -9 to +9.
Proceed step by step.
1.3 FinecorrectionofnallimitpositionOPEN
1.4 FinecorrectionofnallimitpositionCLOSE
1.5 Fine correction of the safety edge‘s pre-limit
_.9 -
_
.9 _.9 = CorrectionindirectionofnallimitpositionCLOSE
_
.9
=CorrectionindirectionofnallimitpositionOPEN
Use menu item P 2.1 to activate or deactivate the safety edge inthe
pre-limit area.
1.6 Door positions for intermediate open
Use this menu item to set an intermediate open. An
intermediateopenisadoorpositionbetweennallimitposition
OPENandnallimitpositionCLOSED.
For this purpose, you must install an external switch on
terminals X8. With this switch, you can activate and deactivate
the intermediate open approach.
Door movement without function of the safety devices!
▪ Block the door for pedestrians and vehicles while adjusting.
1.6 Setting the door position for intermediate open
▪ Move to the desired door position using the OPENorCLOSE button.
▪ Save the door position by pressing the STOP button once.
