GFA DC 8010 - 3.1 Force monitoring of sectional doors

38
3.1 Force monitoring of sectional doors
Activate this menu item only if you operate a sectional door
with counter-balancing.
Force monitoring detects whether the door also lifts people.
Force monitoring is active from an opening width of approx.
2“ (5cm) to 79“ (2m). Slowly advancing changes, such as
decreasing spring tension, are compensated automatically.
During force monitoring, the door control measures the
speed of the door movement. If the current door movement
is slower than the previous one by more than the percentage
specied,forcemonitoringtriggersandstopsthedoor.
Afterwards, the operating mode hold-to-run is active and
error message
F 4.1 appears.
In the case of severe temperature changes or high wind loads,
force monitoring may trigger unintentionally.
Force monitoring does not replace any safety measures
against entanglement by the door!
This function is only a supplement to safety measures.
▪ Take additional measures.
3.1
Force monitoring of sectional doors
►
. 0
Deactivated.
.2 - 1.0
Selectableisaspeeddi󰀨erencefrom2%to10%.
Teaching-in of the function
After exiting programming, you need to move the door once
inself-holdtonallimitpositionOPENandnallimitposition
CLOSED.
You cannot select force monitoring in combination with operating
mode (
0.1) hold-to-run.
