GFA DC 8010 - 0.2 Output rotating direction; 1.1;1.2 Coarse correction of final limit position

29
0.2 Output rotating direction
Use this menu item to change the output rotation direction of the
door drive unit.
0.2 Changing the output rotating direction
Select the options with the OPEN orCLOSEbutton
. 0
Maintaining the output rotation direction.
Exit the menu item by pressing the selector switch.
. 1
Changing the output rotating direction.
Save and exit the menu item by pressing the STOP button for 3 seconds.
1.1/1.2Coarsecorrectionofnallimitposition
Usethesemenuitemstomodifythenallimitpositionsofthe
door that have been already set.
Door movement without function of the safety devices!
▪ Block the door for pedestrians and vehicles while adjusting.
1.1 CoarsecorrectionofnallimitpositionOPEN
1.2 CoarsecorrectionofnallimitpositionCLOSE
▪ Move to the desired door position using the OPEN or CLOSEbutton.
▪ Save the door position by pressing the STOP button once.
