31
1.7/1.8 Switching position of relays X20/X21
You only have to teach-in this switching position if you want to
use the options
.1 / .2 or 1. 1 of menu item 2.7 or 2.8.
With this menu item you can set the door position in which
relays X20 and X21 switch. To use this function, you must set
menu item P 2.7/P 2.8 and connect a device to X20 and/or X21.
Door movement without function of the safety devices!
▪ Block the door for pedestrians and vehicles while adjusting.
1.7
Setting the switching position of relay X20
1.8
Setting the switching position of relay X21
▪ Move to the desired door position using theOPENorCLOSEbutton.
▪ Save the door position by pressing the STOP button once.
2.1 Safety edge in pre-limit area
Use this menu item to activate or deactivate the safety edge
in the pre-limit area. The pre-limit area will be calculated
automatically, it is maximum 50mm (1.96“).
2.1
Safety edge in pre-limit area
►
. 1
Activated.
.2
Deactivated.
