GFA DC 8010 - 2.7;2.8 Relay functions of X20;X21

36
2.7/2.8 Relay functions of X20/X21
Use menu item 2.7 to control the function of X20. Use menu
item
2.8 to control the function of X21. Both menu items have
the same options. Terminals X20 und X21 are potential-free
relay contacts.
2.7
Relay functions of X20
2.8
Relay functions of X21
►
.0
Deactivated.
. 1
Impulse of 1 second during OPEN operation at switching position.
Switching position requires teach-in with
1.7/P1.8.
.2
Permanent contact from switching position.
Switching position requires teach-in with
1.7/P1.8.
.3
Red light: permanent contact during door movement.
InnallimitpositionOPEN:ashingfor3seconds.
InnallimitpositionCLOSE:ashingfor3seconds.
.4
Red light: permanent contact during door movement.
InnallimitpositionOPEN:ashingfor3seconds.
InnallimitpositionCLOSE:o󰀨.
.5
Flashing light: permanent contact during door movement.
InnallimitpositionOPEN:lightsupfor3seconds.
InnallimitpositionCLOSE:lightsupfor3seconds.
.6
Flashing light: permanent contact during door movement.
InnallimitpositionOPEN:lightsupfor3seconds.
InnallimitpositionCLOSE:o󰀨.
.7
Greenlight:o󰀨duringdoormovement.
InnallimitpositionOPEN:permanentcontact.
InnallimitpositionCLOSE:o󰀨.
Instead of green light, for example: usable for the clearance of a dock leveler.
.8 InnallimitpositionCLOSE:permanentcontact.
1.0 Impulse of 1 second with OPEN command.
1. 1
Impulse when switching position is exceeded.
Permanent contact when stopping in switching position.
Switching position requires teach-in with
1.7/P1.8.
