Publication 21555, Rev. E, September 2002 6-1
6
Parts Lists
6.1 Introduction
This chapter contains the parts lists for all assemblies in the 58542 VXIbus Universal Power Meter. Each
parts list includes the CAGE identifier. A list of manufacturers is in Section 6.3.
6.2 58542 VXIbus Universal Power Meter Parts Lists
58542 VXI POWER METER, REV: E
Item P/N Qty Cage Mfr’s P/N Description
32273 REF 58900 32273 MODEL 58542 LAB WINDOWS
1 21383-A00 1 58900 21383-A00 58542,VXI CHASSIS ASSY
2 21555 1 58900 21555 MANUAL,MODEL 58542
3 21373 1 58900 21373 COVER,RT SIDE
4 21461 1 58900 21461 INSULATOR,RIGHT SIDE
5 20954-001 2 54516 20954-001 DET EXT CABLE ASSY 1.5M (5 FT)
6 21556 2 58900 21556 LABEL, ESD
7 PS00-00005 1 0GAA9 3001418 STATIC SHIELDING BAG
8 32442 REF 58900 32442 OUTLINE DRAWING FOR 58542 VXI
21383-A00 58542, VXI CHASSIS ASSY, REV: H
Item P/N Qty Cage Mfr’s P/N Description
30008 REF 58900 30008 58542 PRETEST PROCEDURE
1 21375 1 58900 21375 FRT PNL,MODEL 58542 (VXI)
2 30009 REF 58900 30009 58542 CAL PROCEDURE
3 30010 REF 58900 30010 58542 SYSTEM TEST PROC
4 30018 REF 58900 30018 58542 SERIES JIT FLOW CHART
5 21374 1 58900 21374 COVER,LT SIDE
6 10129 1 58900 10129 LABEL, CODE AND SERIAL NUMBER
7 21462 1 58900 21462 INSULATOR,LEFT SIDE
8 HEH0-00001 1 58900 HEH0-00001 EXTRACTOR HANDLE
9 HEH0-00002 1 58900 HEH0-00002 EXTRACTOR HANDLE
10 21414 2 58900 21414 LABEL,VXI LOGO
11 20192 1 58900 20192 SHELL,OBLONG
12 20259 1 58900 20259 COVER,CALIBRATOR HOUSING
