Giga-tronics 58542 - Preset Configuration; Table 2-4: Reset & Power on Default Commands

58542 VXIbus Universal Power Meter
2-50 Publication 21555, Rev. E, September 2002
2.5.29 Preset Configuration
■ *RST
■ STATus:PRESet
■ SYSTem:PRESet
*RST
Example:
OUTPUT @PWR_MTR;*RST ! RESET 58542 CONFIGURATION
Description:
This command resets the 58542 configuration to a known condition (See Table 2-4). These
are not the power ON conditions. The 58542 has an internal battery which powers a non-
volatile memory chip to retain configuration information. The only configuration that will
change between power OFF and power ON is noted at the end of the table.
STATus:PRESet
Example:
OUTPUT @PWR_MTR;STAT:PRES ! CLEARS ALL THE STATUS REGISTER VALUE
Description:
This command resets the 58542 Status information buffers. See Table 2-4. Note that these
are not the power ON conditions.
SYSTem:PRESet
Example:
OUTPUT @PWR_MTR;SYST:PRES ! RESET 58542 CONFIGURATION
Description:
This command resets the 58542 configuration to a known condition. SYST:PRES is identical
in function to *RST (Command Default, Minimum, Maximum).
Table 2-4: Reset & Power on Default Commands
Command Default Minimum Maximum
CALCulate1[:CHANnel]:
CALCulate2[:CHANnel]:
POWer 1
POWer 2
,
CALCulate1-2:
LIMit
STATe
UPPer
LOWer
FAIL?
FCOunt?
MAXimum:
STATe
[MAGnitude]
MINimum:
STATe
[MAGnitude]
MODE
REFerence:
STATe
[MAGnitude]
STATe
UNIT
OFF
299.999
-299.999
0
0
OFF
299.999
OFF
-299.99
NORmal
OFF
0
ON
dBm
-299.999
-299.999
-299.999
-29.999
-299.99
299.999
299.999
299.999
29.99
299.99
INITiate:CONTinuous OFF ,
