Giga-tronics 58542 - Pcb Assy,Digital, Rev: K1

Parts Lists
Publication 21555, Rev. E, September 2002 6-25
XU 32 JSP0-10014 1 09769 2-641609-1 14 PIN DIP SOCKET
XU 33 JSP0-10016 1 09769 2-614610-2 16 PIN DIP SOCKET
XU 34 JSP0-10014 1 09769 2-641609-1 14 PIN DIP SOCKET
XU 36 JSP0-10014 1 09769 2-641609-1 14 PIN DIP SOCKET
21356 PCB ASSY, DIGITAL, REV: K1
Item P/N Qty Cage Mfr’s P/N Description
1 21355 1 58900 21355 PCB,DIGITAL
2 21357 REF 58900 21357 SCHEMATIC,DIGITAL PCB
3 WTT0-24001 1 29005 #24AWG-TFE/TW #24 TEFLON SLEEVE
4 XAR0-03140 REF 05AJ8 3140 RTV SEALANT
5 WSB0-22000 REF 16428 8021-C1000-22AWG 22 GAUGE BUS WIRE
C 1 CE25-R7100 1 00656 AMR101M025 100 UF 25V RADIAL LEAD
C 2 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 3 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 4 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 5 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 6 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 7 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 8 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 9 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 10 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 11 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 12 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 13 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 14 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 15 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 16 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 17 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 18 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 19 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 20 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 21 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 22 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 23 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 24 CE25-07100 1 55680 TVX1E101MAA 100UF 25V ELECTROLYTIC
C 25 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 26 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C 27 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C 28 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C 29 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C 30 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C 31 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C 32 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
C 33 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO
21359-A00 PCB ASSY PRE-WAVE, ANALOG VXI, REV: N (Continued)
Item P/N Qty Cage Mfr’s P/N Description
