Introduction
Publication 21555, Rev. E, September 2002 1-9
1.2.8 General Specifications
Temperature Range
Operating
0 °C - 50 °C (32 °F - 122 °F)
Operating the 58542 Power Meter in a high level RF field (Approximately 3 V/m) may
degrade performance, this degradation occurs at measured levels below -36 dBm and
when the field frequency is nominally between 50 and 1000 MHz
Non-Operating -40 °C - 70 °C (-40 °F - 158 °F)
Physical Characteristics
Dimensions
C-size, single slot VXI standard
30 mm (1.2 in) wide, 234 mm (9.2 in) high, 340 mm (13.4 in) deep
Weight 2.5 kg (5.5 lbs)
Accessories Included
Two detachable sensor cables
