58452 VXIbus Universal Power Meter
1-8 Publication 21555, Rev. E, September 2002
1.2.6 Inputs/Outputs
Note:
1. Operates in Normal Mode only.
1.2.7 Power Requirements
Analog Output
Provides an output voltage (at the Analog Out BNC) that is configurable from -10 - +10 V from either Channel 1 or Channel 2 in either
Lin or Log units
1
Accuracy
1.0% ±32 mV, -10 - +10 V
Linearity
<0.3%
Trigger Input
Connects EXT trigger (at the EXT TRIG BNC). TTL level input signal for fast reading of buffered data modes
Voltage Proportional to Frequency (in GHz)
Automated Cal Factor correction. Input the analog VpropF signal level from the microwave signal source to the V
PROP
F IN BNC
1
Input Range
0 - 10 V
Accuracy
1.0% ±32 mV (14 bit) (0.6 mV resolution)
Requirements
+5 Vdc @ 800 mA
+24 Vdc @ 250 mA
-24 Vdc @ 250 mA
