Giga-tronics 58542 - Pcb Assy,Analog VXI, Rev: R

58542 VXIbus Universal Power Meter
6-2 Publication 21555, Rev. E, September 2002
13 20800 1 58900 20800 LABEL,US PATENT 4,794,325
14 20112 1 58900 20112 CALIB THERM OVEN PCB ASSY
101 HNKS-44004 4 58900 HNKS-44004 4-40 KEP NUT
102 HWSS-40300 10 58900 HWSS-40300 #4 X 3/16 SPLIT LOCK
103 HBFP-44003 4 26233 NS139CR440R3 4-40 X 3/16 FLAT
104 HCTX-02511 2 62559 21100-464 GRAY COLLAR SCREW SLEEVE
105 HBPP-44004 10 26233 NS137CR440R4 4-40 X 1/4 PAN
106 21587 3 58900 21587 RING NUT,BNC
107 HBPC-02510 2 58900 HBPC-02510 M2.5 X 10 CHEESE HEAD
108 HCTS-02511 2 58900 HCTS-02511 M2.5 x 11 COLLAR SCREW
109 HWFS-02507 2 58900 HWFS-02507 M2.5 FLAT WASHER
110 HBFP-02508 2 58900 HBFP-02508 M2.5 X 8 RAISED C’SINK
111 70564 REF 58900 70564 VXI ASSEMBLY WORK INSTRU
112 32023 REF 58900 32023 CODE LABEL
A 1 21359 1 58900 21359 PCB ASSY,ANALOG VXI
A 2 21356 1 58900 21356 PCB ASSY,DIGITAL
A 3 21418 1 58900 21418 PCB ASSY,VXI PROCESSOR
BT 1 VB00-00360 1 68630 TL-5242/W 3.6 VOLT LITHIUM BATTERY
U 13 21371 1 58900 21371 PROM SET, VXI DIGITAL
U 14 21371 REF 58900 21371 PROM SET, VXI DIGITAL
U 15 21371 REF 58900 21371 PROM SET, VXI DIGITAL
U 16 21371 REF 58900 21371 PROM SET, VXI DIGITAL
W 1 21442 1 58900 21442 CABLE ASSY,CAL
W 2 21405 1 58900 21405 CABLE ASSY,SENSOR INPUT
W 3 21405 1 58900 21405 CABLE ASSY,SENSOR INPUT
21359 PCB ASSY, ANALOG VXI, REV: R
Item P/N Qty Cage Mfr’s P/N Description
1 21358 1 58900 21358 PCB,ANALOG
2 21360 REF 58900 21360 SCHEMATIC,ANALOG
3 JIA0-01443 4 58900 JIA0-01443 CONTACT POST
4 10091-008 3 58900 10091-008 4-40 X 9/16 SWAGE SPACER
5 10091-007 2 58900 10091-007 STANDOFF,SWAGE,4-40,.750 LG
7 HQH0-00000 2 05820 274-2AB HEATSINK
9 GFU0-01204 0 53387 4504-3/4" 3/4 X 1/4 FOAM TAPE
10 21385 1 58900 21385 COVER,BTM,SENSOR INPUT
11 WTT0-22001 0 16428 #22AWG-TFE/TW #22 CLEAR TFE SLVNG
101 HWSS-40300 8 58900 HWSS-40300 #4 X 3/16 SPLIT LOCK
102 HBPP-44004 12 26233 NS137CR440R4 4-40 X 1/4 PAN
103 16718 0 05AJ8 COMPOUND 340 THERMAL GREASE
104 HNKS-44004 1 58900 HNKS-44004 4-40 KEP NUT
105 HBPP-44005 1 26233 NS137CR440R5 4-40 X 5/16 PAN
106 GFU0-01204 1 53387 4504-3/4" 3/4 X 1/4 FOAM TAPE
21383-A00 58542, VXI CHASSIS ASSY, REV: H (Continued)
Item P/N Qty Cage Mfr’s P/N Description
