Parts Lists

Publication 21555, Rev. E, September 2002 6-3

107 HSCS-40204 3 ----- BR6921B-0.156-34 4-40 x 5/32 SWAGE SPACER

112 20260 1 ----- 20260 HOUSING,CALIBRATOR

114 21384 1 58900 21384 COVER,TOP,SENSOR INPUT

C 10 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 11 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 12 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 13 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 14 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 15 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 17 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 18 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 19 CD00-02100 1 ----- CM05E102 1000 PF DIP MICA

C 20 CD00-02100 1 ----- CM05E102 1000 PF DIP MICA

C 21 CD00-02100 1 ----- CM05E102 1000 PF DIP MICA

C 22 CD00-02100 1 ----- CM05E102 1000 PF DIP MICA

C 23 CD99-01820 1 ----- DM15821F 820 PF 300V DIP MICA

C 24 CD99-01820 1 ----- DM15821F 820 PF 300V DIP MICA

C 25 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 26 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 27 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 28 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 29 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 30 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 31 CE50-06100 1 55680 TVX1H100MAA 10UF 50V AXIAL

C 33 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 34 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 35 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 36 CC98-00330 1 ----- CCD-330 33 PF 1KV CERAMIC NPO

C 37 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 38 CC50-04220 1 31433 C330C224MSU5CA .22 UF CERAMIC Z5U

C 39 CF00-04470 1 58900 CF00-04470 .47UF 100V POLYPROPYLENE

C 40 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 41 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 42 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM

C 43 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 44 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM

C 45 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 46 CE50-R5470 1 74840 475PGM050M 4.7UF 50V RADIAL

C 47 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 48 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

21359 PCB ASSY, ANALOG VXI, REV: R (Continued)

Item P/N Qty Cage Mfr’s P/N Description
