1.2 Specifications
Performance specifications describe the 58542 warranted performance, and apply when using the Series
80300A Power Sensors. Typical performance (shown in italics) is non-warranted.
1.2.1 Range
1.2.2 Accuracy
Frequency Range
10 MHz - 40 GHz
1
Power Range
-70 dBm - +47 dBm (100 pW - 50 Watt)
1
Single Sensor Dynamic Range
CW Sensors: 90 dB
1
Peak Power Sensors: 40 dB, Peak
50 dB, CW
1
Calibrator
Power Sweep calibration signal to dynamically linearize the sensors
Frequency
50 MHz nominal
Settability
The 1 mW (0.0 dBm) level in the Power Sweep Calibrator is factory set to ±0.7% traceable to the National Institute of Standards and
Technology (NIST). Measure within 15 seconds of setting calibrator to 0.0 dBm
Accuracy
±1.2% worst case for one year, over temperature range of 5 °C - 35 °C
Connector
Type N(f) connector, 50 W
VSWR
<1.05 dB (Return Loss >33 dB)
