Giga-tronics 58542 - Page 133

Parts Lists
Publication 21555, Rev. E, September 2002 6-7
CR 7 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
CR 8 13618 1 58900 13618 DIODE,uWAVE PIN SW,.3PF,100ns
CR 9 13618 1 58900 13618 DIODE,uWAVE PIN SW,.3PF,100ns
CR 10 13618 1 58900 13618 DIODE,uWAVE PIN SW,.3PF,100ns
CR 11 13618 1 58900 13618 DIODE,uWAVE PIN SW,.3PF,100ns
CR 12 13618 1 58900 13618 DIODE,uWAVE PIN SW,.3PF,100ns
CR 13 13618 1 58900 13618 DIODE,uWAVE PIN SW,.3PF,100ns
CR 14 13618 1 58900 13618 DIODE,uWAVE PIN SW,.3PF,100ns
CR 15 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
CR 16 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
CR 17 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
CR 20 DZAB-00751 1 04713 1N751A 1N751A 5.1V ZENER
CR 21 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
CR 22 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
CR 23 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
CR 24 DSA0-04148 1 58900 DSA0-04148 1N4148 G.P. DIODE
DS 1 ILYR-00200 1 83330 550-0306 RIGHT ANGLE YELLOW LED
DS 2 ILGR-10200 1 08MU3 5300H5 RIGHT ANGLE GREEN LED
DS 3 ILRR-20200 1 83330 550-0406 RIGHT ANGLE RED LED
J 3 JRDF-00008 1 09769 413524-1 BNC F RT ANG PC MOUNT
J 4 JRDF-00008 1 09769 413524-1 BNC F RT ANG PC MOUNT
J 5 JRBM-00100 1 58900 JRBM-00100 SMB M PC MOUNT
J 6 JRDF-00008 1 09769 413524-1 BNC F RT ANG PC MOUNT
J 7 JIA1-07118 1 58900 JIA1-07118 7 PIN STRIPLINE PLUG
J 8 JIA1-07118 1 58900 JIA1-07118 7 PIN STRIPLINE PLUG
J 9 JIA1-07118 1 58900 JIA1-07118 7 PIN STRIPLINE PLUG
J 10 JIA1-07118 1 58900 JIA1-07118 7 PIN STRIPLINE PLUG
L 11 LAB0-05680 1 58900 LAB0-05680 6.8 UH INDUCTOR
L 12 19203 1 OB3G8 19203 .1 UH RF COIL
L 13 15293 1 58900 15293 .17 UH INDUCTOR
L 14 15293 1 58900 15293 .17 UH INDUCTOR
L 15 15293 1 58900 15293 .17 UH INDUCTOR
L 16 LAB0-05680 1 58900 LAB0-05680 6.8 UH INDUCTOR
L 17 LAB0-05680 1 58900 LAB0-05680 6.8 UH INDUCTOR
L 18 LAB0-05680 1 58900 LAB0-05680 6.8 UH INDUCTOR
P 1 JIA2-50318 1 09769 2-87227-5 50 PIN STRIPLINE PLUG
Q 1 QBPP-00170 1 04713 MJE 170 MJE 170 3A 40V 12.5W PNP
Q 2 QBNS-03904 1 04713 2N3904 2N3904 .2A 40V NPN
Q 3 QBNS-03904 1 04713 2N3904 2N3904 .2A 40V NPN
Q 4 QBNP-00231 1 58900 QBNP-00231 BFQ231 1W 1GHZ NPN
21359 PCB ASSY, ANALOG VXI, REV: R (Continued)
Item P/N Qty Cage Mfr’s P/N Description
