Parts Lists
Publication 21555, Rev. E, September 2002 6-9
R 40 RN55-22000 1 91637 RN55C2002F 20 K OHMS 1% MET FILM
R 41 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 42 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 43 RN55-33920 1 91637 RN55C3923F 392 K OHMS 1% MET FILM
R 44 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 45 RN55-31100 1 91637 RN55C1103F 110 K OHMS 1% MET FILM
R 46 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 77 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 78 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 79 RN55-22210 1 91637 RN55C2212F 22.1 K OHMS 1% MET FILM
R 80 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 81 RN55-24750 1 91637 RN55C4752F 47.5 K OHMS 1% MET FILM
R 82 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 83 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 84 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 96 RN55-31000 1 91637 RN55C1003F 100 K OHMS 1% MET FILM
R 97 RN55-11820 1 91637 RN55C1821F 1.82 K OHMS 1% MET FILM
R 98 RN55-14750 1 91637 RN55C4751F 4.75 K OHMS 1% MET FILM
R 99 RN55-00274 1 91637 RN55C27R4F 27.4 OHMS 1% MET FILM
R 100 RN57-25000 1 58900 RN57-25000 50.0 K OHM .1 % MET FILM
R 101 RN57-25000 1 58900 RN57-25000 50.0 K OHM .1 % MET FILM
R 102 RN57-25000 1 58900 RN57-25000 50.0 K OHM .1 % MET FILM
R 103 RN57-25000 1 58900 RN57-25000 50.0 K OHM .1 % MET FILM
R 104 RN55-02000 1 91637 RN55C2000F 200 OHMS 1% MET FILM
R 105 RN55-00511 1 91637 RN55C51R1F 51.1 OHMS 1% MET FILM
R 107 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 108 RN55-03920 1 91637 RN55C3920F 392 OHMS 1% MET FILM
R 113 RN55-24750 1 91637 RN55C4752F 47.5 K OHMS 1% MET FILM
R 114 RN55-11000 1 91637 RN55C1001F 1 K OHMS 1% MET FILM
R 115 RN55-11130 1 1E4C5 RN 1/4 T2 1.13K 1% 1.13 K OHMS 1% MET FILM
R 116 RN55-????? 1 58900 RN55-????? COMPONENT SELECTED IN TEST
R 117 RN57-21500 1 58900 RN57-21500 15.0 K OHM .1 % MET FILM
R 118 RN57-11290 1 58900 RN57-11290 1.29K OHM .1% MET FILM
R 119 RN57-21250 1 60393 GP 1/4-TC50-12.5-.1% 12.5 K OHM .1% MET FILM
R 120 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 121 RN55-41000 1 91637 RN55C1004F 1 M OHMS 1% MET FILM
R 122 RN55-14750 1 91637 RN55C4751F 4.75 K OHMS 1% MET FILM
R 123 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 124 RN55-14750 1 91637 RN55C4751F 4.75 K OHMS 1% MET FILM
R 125 RN55-14750 1 91637 RN55C4751F 4.75 K OHMS 1% MET FILM
21359 PCB ASSY, ANALOG VXI, REV: R (Continued)
Item P/N Qty Cage Mfr’s P/N Description
