Parts Lists

Publication 21555, Rev. E, September 2002 6-15

C 28 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 29 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 30 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 31 CE50-06100 1 55680 TVX1H100MAA 10UF 50V AXIAL

C 33 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 34 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 35 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 36 CC98-00330 1 ----- CCD-330 33 PF 1KV CERAMIC NPO

C 37 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 38 CC50-04220 1 31433 C330C224MSU5CA .22 UF CERAMIC Z5U

C 39 CF00-04470 1 58900 CF00-04470 .47UF 100V POLYPROPYLENE

C 40 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 41 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 42 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM

C 43 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 44 CT20-R6150 1 04222 TAP156K020CCS 15UF 20V TANTALUM

C 45 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 46 CE50-R5470 1 74840 475PGM050M 4.7UF 50V RADIAL

C 47 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 48 CC51-04100 1 04222 SR205C-104KAA .1 UF CERAMIC X7R

C 49 CC50-02220 1 04222 SR151C222KAA 2200PF CERAMIC X7R

C 50 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 51 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R

C 52 CD99-01150 1 ----- DM15-151F 150 PF DIP MICA

C 53 CD99-01240 1 ----- DM15-241F 240 PF DIP MICA

C 54 CC50-02220 1 04222 SR151C222KAA 2200PF CERAMIC X7R

C 55 CD99-00620 1 ----- CMO5FD620F03 62 PF DIP MICA

C 56 CD99-01120 1 ----- CMO6FD121J03 120 PF DIP MICA

C 57 CD99-00620 1 ----- CMO5FD620F03 62 PF DIP MICA

C 58 CD00-02100 1 ----- CM05E102 1000 PF DIP MICA

C 59 CC50-02220 1 04222 SR151C222KAA 2200PF CERAMIC X7R

C 60 CC50-02220 1 04222 SR151C222KAA 2200PF CERAMIC X7R

C 61 CC00-02220 1 04222 SR201A222KAA 2200 PF CERAMIC COG

C 62 CC00-02220 1 04222 SR201A222KAA 2200 PF CERAMIC COG

C 63 CD00-02100 1 ----- CM05E102 1000 PF DIP MICA

C 64 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO

C 65 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO

C 66 CC50-01100 1 04222 SR151A101JAA 100 PF CERAMIC NPO

C 67 CC00-02220 1 04222 SR201A222KAA 2200 PF CERAMIC COG

C 68 CC00-02220 1 04222 SR201A222KAA 2200 PF CERAMIC COG

21359-A00 PCB ASSY PRE-WAVE, ANALOG VXI, REV: N (Continued)

Item P/N Qty Cage Mfr’s P/N Description
