Parts Lists
Publication 21555, Rev. E, September 2002 6-19
L 16 LAB0-05680 1 58900 LAB0-05680 6.8 UH INDUCTOR
L 17 LAB0-05680 1 58900 LAB0-05680 6.8 UH INDUCTOR
L 18 LAB0-05680 1 58900 LAB0-05680 6.8 UH INDUCTOR
P 1 JIA2-50318 1 09769 2-87227-5 50 PIN STRIPLINE PLUG
Q 1 QBPP-00170 1 04713 MJE 170 MJE 170 3A 40V 12.5W PNP
Q 2 QBNS-03904 1 04713 2N3904 2N3904 .2A 40V NPN
Q 3 QBNS-03904 1 04713 2N3904 2N3904 .2A 40V NPN
Q 4 QBNP-00231 1 58900 QBNP-00231 BFQ231 1W 1GHZ NPN
Q 5 QBPS-03644 1 55464 2N3645 2N3644 .3 A 45 V PNP
Q 6 QBNS-03569 1 4U751 2N3569 PN3569 .5A 40V NPN
Q 7 QBNS-03569 1 4U751 2N3569 PN3569 .5A 40V NPN
Q 8 QBNS-03904 1 04713 2N3904 2N3904 .2A 40V NPN
R 1 RN55-31000 1 91637 RN55C1003F 100 K OHMS 1% MET FILM
R 2 RN55-31000 1 91637 RN55C1003F 100 K OHMS 1% MET FILM
R 4 RN55-22000 1 91637 RN55C2002F 20 K OHMS 1% MET FILM
R 5 RN55-22000 1 91637 RN55C2002F 20 K OHMS 1% MET FILM
R 6 RN55-21960 1 91637 RN55C1962F 19.6 K OHMS 1% MET FILM
R 7 RN55-02740 1 91637 RN55C2740F 274 OHMS 1% MET FILM
R 8 RN55-00340 1 58900 RN55-00340 34.0 OHMS 1% MET FILM
R 9 RN55-00097 1 91637 RN55D 9.76 OHM 1% 9.76 OHM 1% MET FILM
R 10 RN55-00340 1 58900 RN55-00340 34.0 OHMS 1% MET FILM
R 11 RN55-02740 1 91637 RN55C2740F 274 OHMS 1% MET FILM
R 12 RN55-21960 1 91637 RN55C1962F 19.6 K OHMS 1% MET FILM
R 15 RN55-22870 1 91637 RN55C2872F 28.7 K OHMS 1% MET FILM
R 16 RN57-27000 1 91637 MFF 1/8 T2 70.0 K OHM .1 % MET FILM
R 17 RN57-18750 1 91637 MFF 1/8 T2 8.75 K OHM .1 % MET FILM
R 18 RN57-11250 1 58900 RN57-11250 1.25 K OHM .1% MET FILM
R 19 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 20 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 21 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 22 RN55-04020 1 91637 RN55C4020F 402 OHMS 1% MET FILM
R 23 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 24 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 25 RN55-13650 1 91637 RN55C3651F 3.65 K OHMS 1% MET FILM
R 26 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 27 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 28 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 29 RN55-21000 1 1E4C5 RN 1/4 T2 10K 1% 10 K OHMS 1% MET FILM
R 30 RN55-11000 1 91637 RN55C1001F 1 K OHMS 1% MET FILM
R 31 RN55-03320 1 91637 RN55C3320F 332 OHMS 1% MET FILM
21359-A00 PCB ASSY PRE-WAVE, ANALOG VXI, REV: N (Continued)
Item P/N Qty Cage Mfr’s P/N Description
