Parts Lists
Publication 21555, Rev. E, September 2002 6-29
C 10 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 11 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 12 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 13 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 14 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 15 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 16 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 17 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 18 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 19 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 20 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 21 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 22 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 23 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
C 24 CE25-07100 1 55680 TVX1E101MAA 100UF 25V ELECTROLYTIC
C 25 CC50-03100 1 54583 RD30HX7R103K .01 UF CERAMIC X7R
J 1 JSE0-20050 1 55322 ESW-125-37-S-D 50 PIN ELEVATED SOCKET
J 2 JIB2-40100 1 91506 A015-040-YE-0013 40 PIN STRIPLINE SOCKET
J 3 JIB2-40100 1 91506 A015-040-YE-0013 40 PIN STRIPLINE SOCKET
J 4 JIB2-36100 1 91506 A015-036-YE-001 36 PIN STRIPLINE SOCKET
J 6 JIR1-04295 1 09769 640453-4 4 PIN RT ANG STRPLN PLUG
L 1 LCC0-00000 1 19701 WBC 2.5/A- 3S4 WIDE-BAND CHOKE
L 2 LCC0-00000 1 19701 WBC 2.5/A- 3S4 WIDE-BAND CHOKE
L 3 LCC0-00000 1 19701 WBC 2.5/A- 3S4 WIDE-BAND CHOKE
R 1 RN55-11000 1 91637 RN55C1001F 1 K OHMS 1% MET FILM
R 2 RN55-03920 1 91637 RN55C3920F 392 OHMS 1% MET FILM
RP 1 RM9S-11000 1 58900 RM9S-11000 1 KOHM X 9 SIP NETWORK
RP 2 RM9S-11000 1 58900 RM9S-11000 1 KOHM X 9 SIP NETWORK
RP 3 RM9S-11000 1 58900 RM9S-11000 1 KOHM X 9 SIP NETWORK
RP 4 RM9S-11000 1 58900 RM9S-11000 1 KOHM X 9 SIP NETWORK
RP 5 RM9S-11000 1 58900 RM9S-11000 1 KOHM X 9 SIP NETWORK
RP 6 RM9S-11000 1 58900 RM9S-11000 1 KOHM X 9 SIP NETWORK
TP 1 ETT0-00001 1 63345 330.100W/ TIN PLATE TEST JACK PIN
TP 2 ETT0-00001 1 63345 330.100W/ TIN PLATE TEST JACK PIN
U 1 UTN0-01382 1 01295 74HC138N 74HC138 DECODER/DEMULTIP
U 2 UTN0-01382 1 01295 74HC138N 74HC138 DECODER/DEMULTIP
U 3 UTN0-02443 1 01295 SN74HCT244N SN74HCT244N BUFFER
U 4 UTN0-02453 1 01295 SN74HCT245N 74HCT245 OCTAL BUSXCVR
U 5 UTN0-02453 1 01295 SN74HCT245N 74HCT245 OCTAL BUSXCVR
U 6 UIN0-01210 1 0B0A9 DS1210 DS1210 NONVOL CONTROLLER
U 7 UTN0-03932 1 01295 SN74HC393N 74HC393 BINARY DIVIDE
U 8 UTN0-05402 1 01295 SN74HC540N SN7HC540N OCTAL BUFFER
U 9 UTN0-00322 1 01295 74HC32N 74HC32 QUAD 2 INPUT OR
U 11 UTN0-00042 1 01295 SN74HC04N 74HC04 HEX INVERTER
U 12 UTN0-00052 1 01295 SN74HC05N 74HC05, HEX INVERTER
U 21 UMN0-51001 1 4T165 UPD431000ACZ-70L TC551001BPL-10 1M RAM
U 22 UMN0-51001 1 4T165 UPD431000ACZ-70L TC551001BPL-10 1M RAM
21356-A00 PCB ASSY, PRE-WAVE, DIGITAL VXI, REV: D (Continued)
Item P/N Qty Cage Mfr’s P/N Description
