A.3 GC and Autosampler Input/Output Configuration
Parameter Name
Default Value
Allowed Range
OPTIC – Autosampler Ready Out
Low to High
Low to High /High to Low
OPTIC – GC Interface
OPTIC Master
Master/Slave
Master
Ready In
High to Low
Low to High /High to Low
Ready Out
Disabled High
Disabled High/Disabled Low
Slave
Ready In
Disabled
Disabled
Ready Out
Low to High
Low to High /High to Low
Run Out Polarity
Low to High
Low to High /High to Low
Run Out Timing
Run On Inlet Ramp
Run On Inlet Ramp/Run on Cryo Ramp
A.4 GC Column and Carrier Gas Parameters
Parameter Name
Default Value
Allowed Range
Single
Column
Internal Column Diameter
0.25 mm
0 - 1 mm
Column Length
30 m
0 - 100 m
Multiple
Columns
Column in Series – One Detector
See configuration tab
Column in Series – Two Detectors
See configuration tab
Flow Modulation – One Detector
See configuration tab
Flow Modulation – One Detector
See configuration tab
Reversed Flow Modulation – Two
Detectors
See configuration tab
Dean’s Switch – Two Detectors
See configuration tab
Dean’s Switch – Three Detectors
See configuration tab
Carrier Gas
He
He/N
2
/H
2
Primary Column Outlet Condition
Atm
Atm/Positive
Pressure/Vacuum
Primary Column Outlet Pressure (Absolute)
101.33 kPa
0 – 700.0 kPa
A.5 Auxiliary Outputs Parameters
Parameter Name
Default Value
Allowed Range
Auxiliary Output 1
Open
Open/Closed
Auxiliary Output 2
Open
Open/Closed
Auxiliary Output 3
Open
Open/Closed
Auxiliary Output 4
Open
Open/Closed
Modulation
No
Yes/No
