4.7.5 Cryotrap Electrical Connections
WARNING!
The control unit should be disconnected from the mains supply until all the
electrical connections are made.
1. Connect the trap assembly to the CryoFocus-4 control unit using a cryotrap power cable and
a thermocouple extension cable (2406-4043) supplied with the instrument.
2. Connect ‘Cryptrap C. Valve’ port on the back of CryoFocus-4 controller to the cryogenic
valve. Use the cryogenic valve extension cable supplied with the system (2406-4112).
For more details, refer to the instructions supplied with the cryotrap installation kit.
