B.4 Auxiliary Outputs
The auxiliary outputs are provided on a sub-D 15 pin female connector. Pin table is shown below.
Pin
Signal
Remarks
1
Power output
+24V  20 %. Max. current 250 mA
9(COM), 2(NO), 10(NC)
Auxiliary Out 1
Relay output (max. 30 V/500 mA)
3(COM), 11(NO), 4(NC)
Auxiliary Out 2
Relay output (max. 30 V/500 mA)
6(COM), 14(NO), 7(NC)
Auxiliary Out 3
Relay output (max. 30 V/500 mA)
12(COM), 5(NO), 13(NC)
Auxiliary Out 4
Relay output (max. 30 V/500 mA)
8
GND
