FC9000-UM-251-9370 12-6
12 Target electrical component for WEEE instruction
(4) Disconnect the control panel exible cables from the control panel board.
Control panel board
Control panel exible cable
(5) Disconnect the LCD exible cable from the control board.
Control panel cover
Control panel board
LCD
LCD exible cable
(6) Remove the seven M2L5 self-tapping screws holding the control panel board, and then detach the
control panel board from the control panel cover.
Control panel cover
Control panel board
M2L5 self tapping screw
M2L5 self tapping screw
To Next Page
