Gravotech M20 - Description of the Machine; M20: Front View of the Machine; X84; Engraving Table

18
M_M20 series V3_EN_C
H. Description of the machine
1. M20: Front view of the machine
 Engraving table
1
7
2
4
5
8
6
3
1. Spindle pressure adjustment button (4 positions)
2. Tool holder assembly
3. Jig(s)
4. Vice
5. Jawopeningandclosingadjustmentknob
6. Frame
7. Controlpanel(9-key󰘱exiblekeypad)
8. On/O󰘯switch
