Adaptable accessories
 Lockingthemountingbracket(Tablet)
1. Tighten the screw(s).
2. Replace the protective cap(s).
 Assembly: Chip collector
Thissystemvacuumschipsfromthemarkingarea.
Opening for the suction hose
Panel with no suction system
