Adaptable accessories
1
2
3
1. Install the suction nose of the suction hose on the
machine spindle.
2. Install the end stop.
3. Start the screws.
Fit the vacuum hose.
Bottom view
1
2
3
1. Screw
2. Stop
3. Vacuum nose
 Security mode
The machine is in mode: Non-safe movement (by default).
• Enable/disable: Security mode.
1. Activate:
Press:Shift+Downarrow+Leftarrow(for3seconds).
Themachineemitsanaudiblesignal(thelight󰘱ashes:highspeed).
2. Deactivate:
Press:Shift+Downarrow+Rightarrow(for3seconds).
Themachineemitsanaudiblesignal(thelight󰘱ashes:lowspeed).
