Gravotech M20 - Side View of the Machine; Control Panel

24
M_M20 series V3_EN_C
Description of the machine
4. Side view of the machine
1 2 3 4
1. On/O󰘯switch
2. Standardinput/outputlink
3. Power inlet / outlet
4. Port: USB
5. Control panel
Start Engraving start
Pause Markingsuspended
"Check"key
Z Activation/deactivation of Z axis travel
Joystick Head movement (X, Y, Z)
Shift
