Description of the machine
+
+
+
+
Movement: X+ Y-
Movement: X+ Y+
Movement: X- Y-
Movement: X- Y+
+
Continuous cycle
+ +
Continuous cycle - end-of-travel return
+
Adjustment: X-Y Origin
+
Adjustment: Automatic ZRef.
+
Clearance position: X=50, Y=0
+
Return to origin
+
Automatic ZRef.
+
=
Rotationofthespindle(On/O󰘯)
(function not available for the M20 PIX machine)
+
=
Positioningpointer(On/O󰘯)
Red pointer
+ +
Safemovement:ON(Presssimultaneouslyonthekeys)
