42
M_M20 series V3_EN_C
Using the machine
• Engraving: no nose
- Manual Z
1. Con󰄈guration
- Select: Zref: None.
- Adjusting the engraving depth
- From the program, transfer the composition to the machine.
2. Position the tool carrier above the object (by pressing keys on the machine keyboard).
3. Headmovesforwardtoparttobemarked:Pressthekey:Z.PresstheDownkey.
4. Insert the cutter into the spindle until it comes into contact with the material to be engraved. Secure
thetool.Pressthe"Check"key.Theheadrises.
5. Start-upengraving:Pressthekey:Start.
Oncethissettingoperationhasbeencarriedout:Toengraveaplateofthesamethicknesswiththesame
settings, omit steps 2 to 5.
- Automatic ZRef (Diamond engraving)
1. Con󰄈guration
- Select:"AutomaticZRef(Diamond)".
- Choose a depth of between 0 and 1 mm (0.039 in) according to the desired pressure.
- From the program, transfer the composition to the machine.
2. Start-upengraving:Pressthekey:Start.
 Setting the origin of the tool carrier: M20 / M20 JEWEL
1. PressZ.PositionthedesiredoriginpointusingtheUp-Downarrows.
2. StorethepositionoftheZzeropointby pressingthe"Check"key for3seconds.The machine
emits an audible signal.
The tool holder is raised.
