Gravotech M20 - X84; Using the Program

47
M_M20 series V3_EN_C
Using the machine
 Using the program
1. Select outside or inside engraving.
2. Indicate the diameter and width of the reference ring according to the desired marking.
3. Choose a depth of between 0 and 0.5 mm (0.020 in) according to the desired pressure.
4. Zclearance:0.5mm(0.020in)
5. Select:"AutomaticZRef(Diamond)".
Enter the data below:
Width
Inside engraving
Internal diameter:
12.5 mm (0.492 in) - 24 mm (0.945 in)
Width (Maximum):
9 mm (0.354 in)
Outside engraving
External diameter:
12.5 mm (0.492 in) - 27 mm (1.063 in)
Width (Maximum): 18 mm (0.709 in)
Forgoodengravingqualityonrings,limittheengravingspeedto5mm(0.197in)/s.
