I. Recommendations for installation
Turno󰓐themachinebeforeanyintervention(puttheOn/O󰓐switchinthe"O"(O󰓐)
position).
1. Physical installation
• Onlytrainedpersonnelawareoftherisksposedbythemachineareauthorizedtointegrate,startanduse
it (training tool: operating and maintenance manual)
• Placethemachineonahorizontal,stableandcleansurfacethatcansupport100kg(220.462lb)ormore.
• Place the machine in a clean, ventilated environment.
• Ambient light is enough to light the equipment properly.
• Arrangetheworksurfaceforrapidandeasyaccesstoeachexternalpartofthemachineand,ifnecessary,
to the main machine stop button.
• Do not obstruct the movement of the moving parts of the machine.
Fasten the machine to the table in order to prevent it
from tipping.
Unscrew the 4 feet by hand.
Drill the support. Attach the machine with 4 M5 screws
ofalengthadaptedtothethicknessofthesupport.
