Gravotech M20 - Engraving Characteristics

82
M_M20 series V3_EN_C
Technicalspeci󰘰cations
2. Engraving characteristics
M20/M20JEWEL M20 PEN M20 PIX
Opening the vice (Maximum) 105 mm (4.134 in)
ClearanceunderspindleZ
(Maximum)
40 mm (1.575 in) -
100 mm (3.937 in)
32 mm (1.260 in) -
92 mm (3.622 in)
-
ClearanceunderspindleZ:with
jigs+standardnose(Maximum)
20 mm (0.787 in) -
80 mm (3.150 in)
Scaledknobfully
tightened
12 mm (0.472 in) -
72 mm (2.835 in)
Scaledknobfully
tightened
16 mm (0.630 in) -
76 mm (2.992 in)
ClearanceunderspindleZ:with
jigs - no nose (Maximum)
28 mm (1.102 in) -
88 mm (3.465 in)
26 mm (1.024 in) -
86 mm (3.386 in)
Clearance under spindle
Z(Total):standardnose
(Maximum)
38 mm (1.496 in) -
ClearanceunderspindleZ
(total):nonose(Maximum)
45 mm (1.772 in) - 105 mm (4.134 in)
37 mm (1.457 in) -
97 mm (3.819 in)
AutomaticadjustmentoftheZ
origin(AutomaticZRef.)
Yes
Red pointer Laser diode < 1 mW - 650 nm
Engraving precision along XY
(Maximum)
< 0.2 mm (0.008 in) < 0.5% of the movement value
Type of spindle(s)
Rotating spindle / through spindle with cutter button
brushless motor
Tool holder: Fixed
Diameter (tool) 4.36 mm (0.172 in) 3.17 mm (0.125 in)
Speed of rotation (Maximum) 19200 rpm -
Power 25 W -
Depth regulating nose
Compatible with all the depth regulating noses
Gravotech
-
