M_M20 series V3_EN_C
Technicalspeci󰘰cations
 Movement speed
Axis
For all machines
Movementspeed:Noload(Maximum) X,Y 40 mm (1.575 in)/s
Z 40 mm (1.575 in)/s
Movementspeed:Engraving(Maximum) X,Y 40 mm (1.575 in)/s
Z 40 mm (1.575 in)/s
Movementspeed:Diamondengraving
(Maximum)
X,Y 40 mm (1.575 in)/s
Z 40 mm (1.575 in)/s
Acceleration:Engraving(Maximum) X,Y 1000 mm (39.370 in)/s²
Z 1000 mm (39.370 in)/s²
Acceleration:
PIX mode (Maximum)
X,Y 5000 mm (196.850 in)/s²
Z 15000 mm (590.550 in)/s²
Repeatability - < 0.05 mm (0.002 in)
 M20 JEWEL (ring engraving)
Internal diameter (Minimum - Maximum)
Width (Maximum)
12.5 mm (0.492 in) - 24 mm (0.945 in)
9 mm (0.354 in)
Forinteriorclamping:
External diameter (Minimum - Maximum)
Width (Maximum)
12.5 mm (0.492 in) - 27 mm (1.063 in)
18 mm (0.709 in)
For exterior clamping (Plain band wedding
ring):
External diameter (Minimum - Maximum)
Width (Maximum)
12.5 mm (0.492 in) - 26 mm (1.024 in)
18 mm (0.709 in)
 M20 JEWEL (Cup)
Diameter:
Minimum
Maximum
10 mm (0.394 in)
80 mm (3.150 in)
Width:
Minimum
Maximum
2 mm (0.079 in)
130 mm (5.118 in)
Diameter 1
Forinteriorclamping(Outsidemarking):
Minimum
Maximum
20 mm (0.787 in)
89 mm (3.504 in)
Diameter 2
Forexteriorclamping(Insidemarking):
Minimum
Maximum
5 mm (0.197 in)
65 mm (2.559 in)
