Adaptable accessories
2. M20 JEWEL: ring engraving (Built-in system mounted in factory)
The cylinder attachment is an accessory designed to clamp objects that are cylindrical or conical in shape
(Outside engraving - Inside engraving)
 Engraving tool(s): Rest position --> Engraving position on a ring
1. Unscrew the locking buttons. 2. Lower the tool.
3. Pivotthetool(1/4revolution).
4. Raise the tool. 5. Tighten the locking knob --> Engraving
position on a ring
