Technicalspeci󰘰cations
M20 CUBE
TraveldistanceZ 30 mm (1.181 in)
ClearanceunderspindleZ
(Maximum)
40 mm (1.575 in) - 100 mm (3.937 in)
Surface󰄉atness
< 0.1 mm (0.004 in) (Vice)
Diameter Pen/Cup
Depthregulatingnose:standardnose
Scaled knob fully tightened
Minimum 20
Maximum 70
Depthregulatingnose:3.3mm(0.130in)
Scaled knob fully tightened
Minimum 4
Maximum 54
Depthregulatingnose:diamondpoint-󰄈xed
Scaled knob fully tightened
Minimum 20
Maximum 70
Depthregulatingnose:diamondpoint-󰄈xed
(L16)
Scaled knob fully tightened
Minimum 5
Maximum 55
