Gravotech M20 - Page 80

80
M_M20 series V3_EN_C
Technicalspeci󰘰cations
M20 - M20 PIX M20 JEWEL M20 PEN
ClearanceunderspindleZ
(Maximum)
40 mm (1.575 in) - 100 mm (3.937 in)
Surface󰄉atness < 0.1 mm (0.004 in) (Vice)
M20 CUBE
Dimensions(Lxwxh):Machine
Netweight:Machine
(no accessories)
15kg(33.069lb)
Dimensions(LxDxH):with
packaging
480 mm (18.898 in) x 500 mm (19.685 in) x 600 mm (23.622 in)
Weight:withpackaging 20.7kg(45.636lb)
Engraving area
(useful surface area)
100 mm (3.937 in) x 100 mm (3.937 in) / 120 mm (4.724 in) x 100 mm (3.937 in)
(Maximum)
Engraving area
(with chuck)
-
Objecttobeengraved:
Dimensions
190 mm (7.480 in) x 110 mm (4.331 in) (Maximum)
